Termination

Products

Datasheet TER-4G-100W-N  (50 Ohm, Nm, 100W, DC-4GHz Power Termination).

Datasheet TER-4G-1W-Nm (50 Ohm, Nf, 1W, DC-4GHz Power Termination).

Datasheet TER-4G-50W-Nm (50 Ohm, Nm, 50W, DC-4GHz Power Termination).

Datasheet TER-3G-1W-Sm  (50 Ohm, SMA male, 1W, DC-3GHz Power Termination).

Attenuators  (DC-12 GHz : 300W “3,6,10,20,30 dB” to 300w CW).


P/NFrequency Range (GHz)VSWR
(Max.)
Average Power (Watts)Connectors
TER-3G-1W-SM
DC-1 GHz
1.20:1
1
SMA male
TER-4G-2W-Nm
DC-4 GHz
1.20:1
2
N male
TER-4G-50W-Nm
DC-4 GHz
1.20:1
50
N male
TER-3G-400W-TNCF
1.2-2.9 GHz
1.20:1
400
TNC female
TER-8G-100W-TNCF
6.8-7.1 GHz
1.20:1
100
TNC female
TER-4G-100W-Nm
DC-4 GHz
1.20:1
100
N male
